Beiben NG80B Heavy Duty Tipper Dump Truck 375hp 6X4 5.6m
Product Details:
| Place of Origin: | China |
| Brand Name: | Beiben |
| Model Number: | NG80 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 45,000USD per Unit |
| Packaging Details: | Suitable for RORO or Bulk cargo ship |
| Delivery Time: | 65 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 500 units per month |
|
Detail Information |
|||
| Name: | Beiben NG80B Heavy Truck 375hp 6X4 5.6m Dump Truck (ND5250ZLJZ13) | Key Words: | Beiben Truck, 6*4 Truck, Tipper Truck, 6*4 Tipper, Dump Truck |
|---|---|---|---|
| Dimension: | 8375*2550*3430mm | Engine: | WEICHAI WP10.350E53 |
| Gearbox: | FAST 12JS160T | Emission Standard: | Euro 3 |
| High Light: | Beiben NG80B Tipper Dump Truck,Beiben NG80B heavy duty dump truck,heavy duty dump truck 375hp 6X4 5.6m |
||
Product Description
Beiben NG80B heavy truck 375hp 6X4 5.6m dump truck (ND5250ZLJZ13)
Beiben Truck, 6*4 Truck, Tipper Truck, 6*4 Tipper, Dump Truck
The cab of this rear eight-wheel dump truck is only a single row. As a dump truck for mining or short-distance transfer, the sleeper has little practical significance for it. It is better to shorten the length of the cab to increase the loading of the cargo box. quantity.
Therefore, its cab looks a little thin from the side, and the "false side windows" are used on the doors on both sides to enhance the visual coordination.
The turn signal is set above the wheel arch. This wide wheel arch is consistent with the NG80 models currently on sale. It is more practical in daily life. The user can use the angle of the wheel arch to complete the climb through the double-deck pedals. It can also effectively prevent the mud stains thrown up when the tires are turned, and maintain the cleanliness of the cab and the cargo box.
The layout on both sides of the vehicle chassis is regular, and it is still not backward compared with the current new models. Both sides are equipped with side guardrails, which can effectively protect the parts, fuel tanks and gas tanks on both sides of the chassis when driving in the construction site. And other parts are made of iron, which has a good performance in durability and hardness.
This strong cargo box looks like a mining dump truck in appearance. Although the Beiben NG80 is an ordinary eight-wheeled rear wheel, its actual loading capacity is comparable to that of a small mining dump truck. The side panels are made of rough ore channel steel, which is very stable in daily transportation, and the "aircraft wing" at the front of the cargo box is also very conspicuous.
| Basic Information | |||
| Announcement model: | ND5250ZLJZ13 | Drive form: | 6X4 |
| Wheelbase: | 3800+1450mm | engine: | Weichai WP10.350E53 |
| Gearbox: | Fast 12JS160T | Rear axle ratio: | 5.263 |
| Body length: | 8.375 meters | Body width: | 2.55 meters |
| Body height: | 3.43 meters | Front track: | 2004mm |
| Rear Track: | 1878/1878mm | Vehicle weight: | 12.26 tons |
| Rated load: | 12.61 tons | Total mass: | 25 tons |
| Tonnage class: | Heavy Truck | Approach angle: | 17 degrees |
| Departure angle: | 25 degree | Origin: | Inner Mongolia Baotou |
| Market segments: | Urban construction waste | Remark: | QH50 power take-off, optional speed ratio 5.921 |
| Overall ratio: | 5.263 | ||
| Engine parameters | |||
| engine model: | Weichai WP10.350E53 | Engine Brand: | Weichai |
| Number of cylinders: | 6 | Fuel type: | diesel fuel |
| Displacement: | 9.726L | Emission Standards: | country five |
| Maximum horsepower: | 350 hp | Maximum output power: | 257kW |
| Max torque: | 1600N m | Maximum torque speed: | 1200-1600rpm |
| Rated speed: | 1900rpm | Engine form: | Electronically controlled high voltage common rail + SCR |
| Cargo box parameters | |||
| Cargo Length: | 5.6 meters | Cargo width: | 2.3 meters |
| Cargo height: | 1.2 meters | Cargo box form: | Back flip self-unloading |
| Cargo Box Type: | U-shaped box | ||
| Cab parameters | |||
| Cab: | NG80B long drive flat roof | ||
| Transmission parameters | |||
| Gearbox Model: | Fast 12JS160T | Gearbox brand: | Fast |
| Forward gear: | 12 gears | Number of reverse gears: | 2 |
| tank | |||
| Fuel tank material: | Aluminum alloy | Fuel tank capacity: | 300L |
| Chassis parameters | |||
| Front axle allowable load: | 7000kg | Description of rear axle: | 13T Beiben Double Reduced Bridge |
| Rear axle allowable load: | 18000 (two-axis group) kg | Speed ratio: | 5.263 |
| Number of spring pieces: | 10/13 | Steering gear: | domestic |
| tire | |||
| Tire specifications: | 11.00R20 18PR,12.00R20 16PR | Number of tires: | 10 |
| control configuration | |||
| ABS Anti-lock Braking: | ● | ||
