10.5m 50+1 Seater CNG City Bus
Product Details:
| Place of Origin: | China |
| Brand Name: | AK |
| Model Number: | 6118G |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD57000per unit |
| Packaging Details: | RORO |
| Delivery Time: | 60 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 500 per month |
|
Detail Information |
|||
| Dimension: | 11490×2500×3330 | Capacity: | 50 Passenger Seats+1 Driver Seat+ 24 Standees |
|---|---|---|---|
| GVW: | 17500 | CNG Gas Cylinder: | 640L, 8 PCS Of 80L CNG Tank |
| Engine: | YC6G260N-50,191kw, 850NM | Gearbox: | Fast Manual 6-speed Transmission |
Product Description
10.5m 50+1 Seater CNG City Bus
| Ⅳ | 技术参数 Technical Specification |
||
| 1.整车参数 Vehicle parameters | |||
| 1.1 | 车辆型号 Bus model |
6118G-Ankai CNG high floor city bus | |
| 1.2 | 座位数 Seat capacity |
50只乘客座椅+1只司机座椅+24站立位 50 passenger seats+1 driver seat+ 24 standees |
|
| 1.3 | 制造日期 Year of manufacturer |
2026 | |
| 1.4 | 载客人数 Passenger capacity |
100 | |
| 1.5 | 尺寸 长*宽*高 (mm) Dimension L*W*H (mm) |
11490×2500×3330 | |
| 1.6 | 接近角/离去角(º) Approach /Departure angle (º) |
7°/7° | |
| 1.7 | 轴距(mm) Wheel base (mm) |
5700 | |
| 1.8 | 前/后悬(mm) Overhang Fr/Rr (mm) |
2600/ 3190 | |
| 1.9 | 整备质量(kg) Kurb weight (kg) |
11000 | |
| 1.10 | 最大总质量(kg) G.V.W (kg) |
17500 | |
| 1.11 | 最高时速(km/h) Max speed (km/h) |
69 | |
| 1.12 | 气瓶总容积(L) Total CNG tank capacity (L) |
640L,8只80L气瓶 640L, 8 PCS of 80L CNG tank |
|
| 1.13 | 气瓶安装位置 CNG cylinder fixing location |
顶置 Roof mounted |
|
| 2.底盘配置 Chassis configuration | |||
| 2.1 | 发动机 Engine |
发动机型号 Engine model |
YC6G260N-50 (Yuchai CNG engine) |
| 发动机位置,燃料,型式 Engine position & type |
后置天然气发动机,立式,直列,水冷,四冲程,增压中冷 Rear-mounted natural gas engine, vertical, inline, water-cooled, four-stroke, turbocharged and intercooled |
||
| 排放标准 Emission |
Euro V | ||
| 排量(L) Displacement (L) |
7.8 | ||
| 额定功率(kw/rpm) Rated power (kw/rpm) |
191/ 2300 | ||
| 最大扭矩(N.m/rpm) Max. torque (N.m/rpm) |
950/ 1300-1700 | ||
| 2.2 | 离合器 Clutch |
国产离合器 With |
|
| 2.3 | 变速箱 Gearbox |
法士特手动六档变速箱 Manual 6-speed transmission |
|
| 2.4 | 缓速器 Retarder |
不带 Without |
|
| 2.5 | 悬架系统 Suspension |
钢板弹簧/前4后5 Leaf spring, front 4 pcs/ Rear 5 pcs |
|
| 2.6 | 前桥 Front axle |
国产5.5T前桥/前盘式制动器 Front disc brake with rated loading capacity: 5.5T |
|
| 2.7 | 后桥 Rear axle |
国产11T后桥/后鼓式制动器 Rear drum brake with rated loading capacity: 11T |
|
| 2.8 | 行车制动 Service brake |
双回路气压制动,自动调整臂 Dual-circuit air brake with automatic slack adjuster |
|
| 2.9 | 驻车制动 Parking brake |
弹簧储能制动 Spring energy storage brake |
|
| 2.10 | ABS | 带ABS,不带ESC With ABS, without ESC |
|
| 2.11 | 拖车钩 Trailer Hook |
带,前拖车钩 With, placed at the front of the bus |
|
| 2.12 | 转向系统 Steering system |
国产动力转向,左舵驾驶 Power steering, left hand driving |
|
| 2.13 | 轮胎 Tyre |
11/R22.5 /6条(朝阳),不带轮罩和备胎 11R 22.5, 6pcs, made in China, without wheel cover and spare tyre |
|
| 3.车身参数 Body parameters | |||
| 3.1 | 空调 Air conditioner |
松芝顶置单冷空调,制冷量28000KCAL/H Songz roof-mounted single cooling air conditioner, cooling capacity 28,000 Kcal/h |
|
| 3.2 | 暖风加热器 Fuel heater |
不带 Without |
|
| 3.3 | 散热器 Radiator |
不带 Without |
|
| 3.4 | 除霜器 Defroster |
标配 With |
|
| 3.5 | 地板革 Floor cover |
灰色石英砂地板革 Grey quartz sand vinyl floor covering |
|
| 3.6 | 扶手 Handrail |
不带 Without |
|
| 3.7 | 司机座椅 Driver seat |
国产司机座带上下,前后调节,三点式安全带 Driver seat made in China with vertical and longitudinal adjustment, equipped with a three-point seat belt |
|
| 3.8 | 司机包围 Driver's seat enclosure |
不带 Without |
|
| 3.9 | 内饰照明 Interior Lighting |
4只内顶灯 4 interior dome lamps |
|
| 3.10 | 视听 Visual/ Sound |
收音机+司机USB接口+司机麦克风+扬声器,不带电视 Radio+ USB interface only for driver+ Microphone only for driver+ Loud speakers, without TV |
|
| 3.11 | 乘客座椅 Passenger seats |
50只公交注塑座椅带软垫,3+2排布 50 plastis bus seats with cushions, arranged in a 3+2 layout |
|
| 3.12 | 轮椅区/残疾人座椅 Wheel chair area/ Seat for disabled |
不带/不带 Without/ Without |
|
| 3.13 | 倒车镜 Rear-view mirror |
手动铁杆式倒车镜 Manual metal-rod type rearview mirror |
|
| 3.14 | 外形/大灯 Model/ Headlight |
C款外型及大灯 Modedl C with headlight |
|
| 3.15 | 组合仪表 Instrument |
国产CAN仪表,不带行车记录仪 CAN instrument panel made in China, without driving recorder |
|
| 3.16 | 油漆 Paint |
国产纯色漆,漆色,图案可免费定制 Pure paint, with color and pattern customizable free of charge |
|
| 3.17 | 安全天窗 Roof emergency exit |
2只带换气功能安全天窗 Two emergency exits with ventilator |
|
| 3.18 | 司机遮阳帘 Sun visor for driver |
带 With |
|
| 3.19 | 安全锤 Safety hammer |
8只安全锤带防盗警报 8 pcs with voice alarm |
|
| 3.20 | 司机门 Driver door |
不带 Without |
|
| 3.21 | 乘客车门 Passenger door |
前单/中双气动内摆门 Front and middle pneumatic inward swing door |
|
| 3.22 | 安全门 Sfety door |
不带 Without |
|
| 3.23 | 前档 Front windshield |
前挡双片式夹胶玻璃 Front windshield in two pieces made of laminated glass with sun-visor |
|
| 3.24 | 侧窗玻璃 Side sindow |
上固定下推拉白色钢化玻璃,不带窗帘 Upper fixed and lower sliding white tempered glass windows, without curtains |
|
| 3.25 | 安全工具 Safety tools |
反光三角牌1个,停车楔2个,反光背心1个,随车简易工具一套,两册一书(使用说明书,零配件图册,维修手册) One reflective warning triangle, two wheel chocks, one reflective safety vest, one set of basic onboard tools, and two manuals plus one book (Operation Manual, Spare Parts Catalogue, and Maintenance Manual) |
|
| 3.26 | 其它 Others |
电子钟,内视镜,2只4kg灭火器,发动机舱自动灭火,简易式司机后档板,倒车报警蜂鸣器,司机电风扇,彩色倒车监视器,8只80L气瓶 Electronic clock, interior rearview mirror, two 4kg fire extinguishers, automatic engine compartment fire extinguishing system, driver partition panel, reversing alarm buzzer, driver’s electric fan, color rearview monitor, and eight 80L gas cylinders |
|
